8v full automatic door lock dc geared motor



Drawing (mm)



Remark: find the length of gearbox "L" in below Technical Data of Gearbox.



Specifications

Specifications below are for reference only. Contact us for more.

Model Number	Rated Volt.	No   Load		At   Max Efficiency				Stall
		Speed	Current	Speed	Current	Torque	Power	Current	Torque
		rpm	mA	rpm	mA	Kgf.cm	W	mA	Kgf.cm
DSD-65OS3900087000-87K	8V	80	350	67	2000	4.4	16W	9000	18Min
DSD-65OS38500811500-149K	8V	77	700	67	1300	1.6	10.4W	10000	19Min
DSD-65OS39500810000-130K	8V	77	850	68	2600	4.4	20.8	15000	20Min
Remark: 1 Kgf.cm≈0.098   N.m≈14 oz.in   1 mm≈0.039 in



What a Model Number Tells You?

We follow some rules to create each model number. A model number would tell you a lot of useful messages. Here is a sample.

So here we can learn that it is a 37mm Round Spur gear motor, 12V driving motor #555, no load input speed 6000rpm and reduction ratio 100:1. Hey, what about output speed? You need to do a little calculation. Input speed 6000rpm ÷reduction ratio 100 = 60rpm.



Technical Data of Motor

Motor model	Rated Volt.	No load		Load				Stall
		Current	Speed	Current	Speed	Torque	power	Torque	Current
	V	mA	r/min	mA	r/min	gf.cm	W	gf.cm	mA
DSD-3950123000	12	≤80	3000	≤450	2100	100	2.2	≥300	≥1020
DSD-3950124500	12	≤120	4500	≤690	3600	100	3.77	≥450	≤2400
DSD-3950126000	12	≤160	6000	≤930	5200	100	5.45	≥675	≥4500
DSD-3950243000	24	≤50	3000	≤200	2100	90	1.98	≥270	≥420
DSD-3950244500	24	≤60	4500	≤200	3480	90	3.28	≥357	≥980
DSD-3950246000	24	≤70	6000	≤430	5000	100	5.24	≥540	≥1730



DIY with Your Gear Motor

With the Technical Data of Gearbox and Technical Data of Motor, now you are ready to DIY with your gear motor. Follow the steps here.

FAQ

Q: Can you make a motor with custom specifications?

A: Yes, actually that is what we do most of the time.

Q: What is delivery time of samples?

A: 1~3 weeks.

Q: What is delivery time of mass production?

A: 4~5 weeks.

Q: What is the MOQ (minimum order quantity)?

A: You can find it in the front of the product pages.

Q: Do you have motors in stock?

A: No, we don’t. All motors are made with orders.

Q: How much does a motor cost?

A: Please send us an inquiry and tell us exactly what you are looking for.

Q: Do you have quality control?

A: Yes, we have a professional QC team.

Q: Are you a real factory?

A: Yes, we are.

Q: How to pay you?

A: a) We prefer PayPal transfer for samples and small amount of money. b) Bank transfer for large amount of money. Regular payment terms: 30% deposit, balance before shipment / against shipping documents.

Q: How do you handle shipment?

A: We recommend DHL Express for samples and small quantities. It is very fast, safe and relatively cheap. b) We arrange shipment by sea and by air and go with FOB/CIF/CFR terms for large quantities.

Q: What do you need to know if I need a recommendation on motor?

A: Normally we need to know dimensions, rated voltage, speed at load/no load, torque at load/stall. i.e. a motor with diameter 37mm, 12V, 100rpm and 2Kgf.cm at load.

Q: Can I ask you for help if I know nothing about motor?

A: Yes, our pleasure. We are nice people with big hearts.

Q: Can I call you?

A: Yes, please call the international sales manager. He’s very good at English.

Available on 9:00 a.m. ~ 10:00 p.m. Chinese time
